Key Features
- Three infrared cameras — a third camera vs the EYE XO delivers expanded hitting area coverage and measurably more accurate data
- 28" × 21" hitting area — more than double the EYE XO's 12" × 15.5". Handles left and right-handed golfers simultaneously
- Flexible hitting zones — configure tee, fairway, rough, and bunker positions. Software adjusts ball metrics based on lie
- 11 club metrics — dynamic loft, face angle, face-to-path, lie angle, loft angle, vertical and horizontal impact point, and more
- 12 ball metrics — angle of descent, flight time, distance to apex, run distance alongside the complete ball data set
- Two Swing Optix cameras included — packaged with every EYE XO2 for full multi-angle swing video analysis
- Overhead-mounted — ceiling or Carl's Place Pro Enclosure. Out of every swing path and foot position
- No marked balls required — tracks all ball data with any standard golf ball
Technical Specifications
| Cameras | 3 infrared cameras (upgrade from EYE XO's 2) |
| Dimensions | 36.3" W × 5.9" D × 2.5" H |
| Hitting Area | 28" wide × 21" deep (vs 12" × 15.5" on EYE XO) |
| Hitting Zones | Tee, Fairway, Rough, Bunker |
| Mounting Type | Overhead — ceiling or Pro Enclosure bracket |
| Mount Height | 9–10 ft above hitting surface (9 ft minimum) |
| Position vs. Tee | 3.5 ft in front of tee position |
| Ball Requirements | Standard golf balls (no markings needed) |
| Club Data | Included club stickers (400 supplied) |
| Swing Analysis | 2 × Swing Optix cameras (included) |
| Included Software | VIEW + Ignite (ball spin & club path replay) |
| OS Requirement | Windows 10 (64-bit) version 1803+ — not Mac compatible |
| Processor | Intel i5 8400 or greater |
| RAM | 8GB minimum (16GB required with Swing Optix) |
| GPU | Nvidia GTX 1060 or AMD Ryzen 3600X+ |
EYE XO2 vs EYE XO — Key Upgrades
Cameras: 3 infrared (vs 2)
Hitting area: 28"×21" (vs 12"×15.5")
Lie zones: Tee / Fairway / Rough / Bunker
Multi-golfer: Left & right together
Trouble Mat: Included
Ball Metrics (12 — standard balls)
Ball Speed
Back Spin
Side Spin
Launch Angle
Side Angle & Total
Carry Distance
Run Distance
Total Distance
Angle of Descent
Flight Time
Distance to Apex
Club Metrics (11 — with stickers)
Club Speed
Angle of Attack
Smash Factor
Club Path
Dynamic Loft
Club Face Angle
Face to Path
Club Lie Angle
Club Loft Angle
Impact Point Vertical
Impact Point Horizontal
In The Box
- EYE XO2 launch monitor unit
- 2 × Swing Optix cameras (packaged separately)
- Mounting bracket with level
- VIEW software download + Ignite software
- 3-month Ultimate Package trial
- Calibration chart
- 11-foot power cable, adapter and connector
- USB Ethernet adapter + 60-foot LAN cable
- 400 EYE XO2 club stickers
- Uneekor Trouble Mat
- M4 and M6 mounting screws
Note: Third-party software (GSPro, E6 Connect) requires a Pro Package ($199/yr) after the 3-month Ultimate trial. Ships to US and Canadian addresses only.
Compatible Software
Important: Third-party software (GSPro, E6 Connect) requires a Pro Package ($199/yr) or above. The included Player Package covers Uneekor VIEW only. A 3-month Ultimate trial is included with every EYE XO2.
VIEW — Included
Virtual driving range, shot analysis, advanced reporting, and lie-aware hitting zones. Windows PC only.
Ignite — Included
Ball spin and club path replay video overlaid on your shot data at the moment of impact.
GSPro (Pro pack required)
200,000+ courses. Separate annual subscription. Windows only.
E6 Connect (Pro pack required)
100+ courses, putting, games. Separate annual license. Windows only.
PC Required: Windows 10 (64-bit) with Ethernet port, Intel i5 8400+, 8GB RAM (16GB with Swing Optix), GTX 1060+. Not compatible with Mac or iOS.
Is This Right For You?
The Family / Multi-User Sim
The 28"×21" hitting area accommodates left and right-handed players simultaneously without re-calibrating. The biggest advantage over the EYE XO for households or commercial bays.
Great fit ✓
The Coach or Commercial Operator
Instructors and bay operators need a large hitting area and lie-zone simulation (rough, bunker, fairway) to replicate real on-course scenarios. The EYE XO2 is purpose-built for this.
Great fit ✓
The Maximum-Data Golfer
Three cameras give the EYE XO2 measurably more accurate data than its two-camera predecessors. If you want the most accurate overhead system available without stepping up to a Trackman-tier price, this is it.
Great fit ✓
The No-Subscription Buyer
GSPro and E6 Connect require a Uneekor Pro package ($199/yr) after the 3-month trial. If zero ongoing platform fees are a priority, consider the NVISAGE NEO-E instead.
Not ideal ✗
Room Size Guide
9–10 ft
Ceiling Height
3.5 ft
In Front of Tee
10–12 ft
From Screen
| Mount height | 9–10 ft above hitting surface (9 ft minimum) |
| Forward position | 3.5 ft in front of tee (6.5 ft+ from screen) |
| Golfer to screen | 10–12 ft minimum |
| Swing area | 14-ft diameter (player centred in bay) |
| Mounting options | Ceiling bracket or Carl's Place Pro Enclosure |
| Wiring | 60-ft LAN cable + 11-ft power cable (both included) |
| Unit width | 36.3" — plan ceiling clearance accordingly |
The EYE XO2 is 36.3" wide — 5" wider than the EYE XO. Confirm your ceiling mount or enclosure frame can accommodate this before ordering.
What You'll Also Need
Carl's Place Pro Enclosure
Bracket compatible — mount the EYE XO2 directly to the frame
View →
HD Impact Screen
High-quality screen for projecting simulation output
View →
Short-Throw Projector
Best-value short-throw for simulator rooms
View →
Hitting Mat
Completes the hitting bay
View →
Also required: Windows 10 PC with Ethernet port, Intel i5 8400+, 8GB RAM (16GB with Swing Optix), GTX 1060+. A Uneekor Pro package ($199/yr) and separate simulator software license required for GSPro or E6 Connect.
Frequently Asked Questions
What's the difference between the EYE XO and the EYE XO2? +
Three key upgrades: (1) A third infrared camera, which expands the hitting area and improves data accuracy. (2) A much larger hitting area — 28"×21" vs 12"×15.5" on the EYE XO. (3) Flexible lie zones (tee, fairway, rough, bunker) that adjust ball metrics based on your simulated lie. The XO2 is also physically wider at 36.3" vs 31". Both include two Swing Optix cameras.
Can left and right-handed players use it at the same time? +
Yes. The expanded 28"×21" hitting area is specifically designed to accommodate both left and right-handed golfers simultaneously without re-positioning the unit — a key advantage for family setups and commercial bays.
What are the flexible hitting zones? +
Within Uneekor VIEW software, you can configure the hitting position as Tee, Fairway, Rough, or Bunker. When you hit from rough or bunker, the software factors in the lie when calculating your ball metrics — making your indoor practice more realistic to on-course play.
Are the Swing Optix cameras included? +
Yes — two Swing Optix high-speed cameras are packaged with every EYE XO2 (shipped separately). They capture multi-angle swing video synced with your shot data. Note: Swing Optix requires 16GB RAM in your PC.
Does it work with GSPro or E6 Connect out of the box? +
Not immediately. The included Player Package gives VIEW access only. A 3-month Ultimate trial is included with purchase, giving full third-party software access during that period. After the trial, a Pro Package ($199/yr) or higher is required.
What is the minimum ceiling height? +
9 feet is the absolute minimum. Ideally 9–10 feet above the hitting surface, with the unit positioned 3.5 feet in front of the tee. The EYE XO2 is 36.3" wide — 5 inches wider than the EYE XO — so confirm your ceiling or enclosure frame can fit it before ordering.
Does it work on Mac? +
No. The EYE XO2 requires Windows 10 (64-bit, version 1803+) and an Ethernet port. Not compatible with macOS or iOS. If you need Mac compatibility, consider the Garmin R50.
What PC do I need? +
Minimum: Intel i5 8400, 8GB RAM (16GB required for Swing Optix), Nvidia GTX 1060 or AMD Ryzen 3600X+, Windows 10 (64-bit) version 1803+, integrated Ethernet port. AMD 2700 is not compatible.
